Building Donor Center Software Processes: Donor Physical Examination and Adverse Reactions

drzeyd

Donor physical examination, along with the donor questionnaire, are important both for donor and patient safety.  In general:

Is it safe for the donor to donate?

Is it safe for the patient to receive the blood even if it is safe for the donor to donate.

Any donor who does not feel well must not donate.  This may be the single most important step in ensuring a safe blood supply.

The donor physical examination includes the vital signs (blood pressure, pulse, temperature, heart rate, and temperature).  I have attached a sample set of criteria for review.  All are user-definable.  Note how the arm examination is also included (looking for scarring, skin lesions, etc.)

For all types of donations, there may be adverse reactions.  These must be documented in the record along with the disposition of the donation.  Will the donor need an extended deferral if the RBCs in the apheresis run are not returned?  This can be built from the reaction documentation.  Note the following sample table of reactions.

To Be Continued

Building Donor Center Processes: Setting Deferral Intervals between Donation Types

drzeyd

Donation can be whole blood or apheresis-based.  The sex and age for each donation type is specified.  At HMC, we did not accept females for platelet or plasma donations, so the starting age is listed as 99 years.  Otherwise, in accordance with Qatari law, the starting age for donation is 18.  All these parameters are user-definable, and a transfusion medicine physician can override the rules if necessary.

For each and every combination of donations, the deferral interval must be specified.  Examples follow.  The temporary deferral period is in days:

Previous donation whole blood, current donation whole blood:  56

Previous donor platelets, current donation whole blood:  2

Previous donation whole blood, current donation platelets:  56

Also note how for each possible combination there is an entry for male AND female.  Females are restricted to whole blood donation and only RBCs will be made from the collection.

If there is a collection incident and the apheresis procedure is not completed, the interval will be set to 56 days.  This will be covered in the post on donor adverse effect reporting.

To Be Continued:

Opinion: Selecting a Pathogen Inactivation System

drzeyd

Transfusion-transmitted infectious disease are a continuing threat.  Despite donor infectious marker testing and new donor questioning, there are many threats which are not addressed by these measures.  Also new pathogens are being identified for which there are no tests or specific donor questions available.  How can we handle these new threats?

Pathogen inactivation can significantly reduce infectious agents in blood components, although the degree varies depends on the agent.  Theoretically any agent with nucleic acid—RNA or DNA is affected.  The only class of agents not affected at all are prions, which have NO nucleic acid at all.

In general, a photoactive agent is added to the blood component which binds to the nucleic acid.  Photoactive agents include riboflavin, psoralen dyes, and methylene blue.  Then the component is irradiated, the time proportional to the volume of the unit.

The component is then exposed to ultraviolet light to photoactivate it, which disrupts the DNA and RNA present, including in the white cells.  Thus, NO irradiation or bacterial culture is required.

Here are my questions to consider when selecting a pathogen inactivation system:

Targets?  Platelets vs plasma vs whole blood?

Methylene may be used for plasma, but riboflavin or psoralens may be used for platelets or plasma.  Whole blood inactivation with riboflavin is CE-approved.

Photoactive dye:  Is it riboflavin vs psoralen vs methylene based?

Riboflavin is vitamin B2—the amount used is small and does not need to be removed whereas the psoralen must be removed for clinical use.

Does the photoactive material need to be removed before transfusion?

You can immediately use the riboflavin-treated component but the psoralen must be removed before transfusion—this may take 6 or 20 hours depending on the licensing of the product.

What is the loss of platelets or coagulation factors after treatment?

With treatment by all methods, there is some loss of platelets and coagulation factors.  The platelet loss may be greater in psoralen-based methods and require additional components be added to the pool to reach the desired dose.  Likewise, plateletpheresis components treated with psoralen may require a recalibration of the donor apheresis equipment to collect more platelets per dose to compensate.  There may be some RBC loss additionally in whole blood pathogen inactivation.

What is the efficacy of pathogen reduction for the infectious agents, particularly the ones in your region?

Example:  How well does the treatment handle local agents like Hepatitis E?  Psoralen agents may be less effective than riboflavin for this agent.

Does it work with platelet additive solution PAS?

There are minimum and maximum volumes for pathogen inactivation set by the manufacturer.  Can you get sufficient yields within these volumes?

How good is the data management system?  Can it be integrated with your blood bank computer system?

Can the equipment be integrated with your system?  This is important to set rules and enforce good manufacturing processes GMP.

Does it work well with an automated blood component production system?

Such automated systems like the Reveos can free up personnel for pathogen inactivation.  Can the volumes produced be handled effectively by the pathogen-inactivation method?  Do the timings for separation of components work synergistically with the pathogen inactivation method?

Vendor issues:  how well will the local agent provide support?  Is someone else in your country or region using the system?

You need an experienced vendor to provide optimal support.

Summary of Accomplishments at Hamad Medical Corporation 2011-2020

drzeyd

2011

Established automated component production using Atreus technology, plasma and platelet pathogen inactivation (Mirasol)—made HMC component production Good Manufacturing System GMP compliant

2011

Qatar is the first to adopt non-PCR-based NAT technology (Grifols/Novartis Tigress) and becomes world reference site for this

2011

Based on the above, Qatar can now completely process all whole blood into blood components (red cells, platelets, and plasma) in as little as 5 hours from collection!

2011-2020:

I established policies and procedures for the hospital blood banks/transfusion services, blood donor center, therapeutic apheresis, and laboratory information systems to bring HMC in compliance with the Council of Europe, international AABB, and other standards.  I customized our own standards for our local needs based on them.

2012-2013

Implemented custom build of the multilingual blood bank computer system (Medinfo) for both patient and donor services, including development of interfaces to all production equipment including Atreus and Mirasol (world’s first) and a direct link to Ministry of the Interior to obtain patient demographics in English and Arabic—Qatar became the world’s first site to combine fully-interfaced, automated component production with pathogen inactivation:  Qatar becomes world reference site for this.

2013-2014

Built, validated, and implemented laboratory build of hospital information system, Cerner Millennium

2015

Replaced and updated Atreus with Reveos automated component production to allow faster throughput and capacity with a full bidirectional interface (world’s first), introduced platelet

additive solution PAS with pathogen inactivation (Mirasol)—Medinfo interfaces updated to Reveos for all equipment:  this doubles the capacity to process whole blood into components using the same physical space

2015-2019

Updated dedicated blood bank software Medinfo Hematos IIG by several versions using Division Head, LIS, and internally trained Super Users—at great cost savings to HMC by not using outside consultants (e.g. Dell Consulting)

2019

Established column absorption technology using Terumo Optia therapeutic apheresis machine for treatment of ABO-incompatible renal transplants:  I validated using the Ortho Vision MAX to perform ABO antibody titers for this system and correlated it with the reference method at Karolinska Institutet in Stockholm (manual gel) to bring rapid throughput and labor savings—Qatar being the first-site in the world to do this.  We saved money by using the same apheresis machine to use this column absorption technology (no need for second machine to use the columns)

2020

Expedited setup (two weeks total) of COVID-19 convalescent plasma production, initially manual and then fully integrated into the Medinfo computer system as a customized module with separate quarantine collection, production, and transfusion service functions

Other:

I was awarded two HMC Star of Excellence Awards:

2013—Liver Transplantation Transfusion Support

2019—ABO-Incompatible Renal Transplantation Support
